CXA-12

Constant curvature line source

High Output, self powered (class D switch mode power supply with PFC), constant curvature line array element.

The CXA-12 enclosure is a constant curvature line array element designed for multiple configurations, with a maximum of 4 enclosures.

The CXA-12 uses one 12″ LF/MF speaker next to a custom Multidriver waveguide system. The enclosure is self-powered with a total of 1400W (Class D, witch mode power supply), with PFC system and DSP processor with linear phase FIR filters.

It is ideal for a wide variety of applications, its design allows you to configure installations with symmetrical dispersion or fly the boxes vertically. The enclosure has a complete range of accessories that facilitate its use both in touring as in fixed installations.

For low frequency support the CXA-18S subwoofer is also available, either to be flown or stacked with the CXA-12 without the need for any rigging accesories.

Perfectly suited for:

Live events
Clubs
Theatres
Houses of worship
Fixed installations
Touring

Transducers: 12″ LF speaker and 1.4″ HF compression driver.
Acoustics: 60 Hz – 20 kHz frequency range with 131 dB Peak SPL.
Coverage: Constant directivity with a defined 80° H x 50° V cobertura.
Crossover: Internal high-quality passive filter with phase correction.
Build: 15 mm birch plywood enclosure finished with high-resistance polyurea.
Hardware: Multiple M8 rigging points and 35 mm pole mount socket.

Components

LF: 12″, 2.5″ voice coil, Malt Cross Cooling System
HF: custom Multidriver system with wave guide, 1.4″ aluminium voice coil with titanium diaphragm

Frequency Range

60 Hz – 20 KHz (-10dB)

Frequency Response

70 Hz – 18 KHz (± 3dB)

Max SPL

128 dB

Coverage

100º H x 18 º V

Power

1400W Class D with switching power supply & PFC
LF Amplifier: 1 x 800 W
HF Amplifier: 1 x 600 W

Processing

Internal Lynx Processor DSPB-FL.
96 KHz / 64 bit double-precision, DSP with FIR filter linear phase

Control

User control interface with 2.8″ IPS screen

Control Connections

Ethernet (OCS) / USB (DSP updating)

Input

Analog / AES3 (optional)

AC Power

90 – 264V. 50/60 Hz with PFC

AC Connections

16A Neutrik powerCon TRUE1 TOP with looping output

Finish

Polyurea coating, black colour

Material

15 mm premium birch plywood

Dimensions

357 x 632 x 484 mm (H x W x D)

Weight

31 kg (68 lbs)

More features

Hardware for CXA-12

Enclosure

The CXA-12 cabinet is constructed from 11-ply premium birch plywood (15mm thickness) and finished with polyurea coating.

Internal design

The internal structure of the CXA-12 is heavily braced for greater longevity and all parts are assembled on metal inserts with metric screws. The amplification modules & DSP are housed in a separate chamber to the drivers avoiding excessive heat & vibration, thus delivering greater efficiency and reliabilit

Rear panel

The powder coated steel rear panel contains all connections and houses the CXA-12s amplification modules and DSP, is easily accessible and housed separately from the drivers for increased reliability and efficiency.

Grill

The CXA-12 has a heavy duty, powder coated front grille with a special acoustic rear fabric to protect the transducers against dust and dirt.

Handles

Handles are integrated in to the side plates of the CXA-12 to facilitate transport, positioning and loading of the cabinets.

Rigging

Integrated flying plates are located on each side of the enclosure, to link CXA-12 cabinets together with optional splay angles, from between 0° to 6° with 0.5° step increments to create the desired curve.

Accesories for CXA-12

BALL-PSR0630

Ball pin with thread for CXA-12 and CXA-18S cabinets

SV-CXA

Flying frame for the CXA-12 with a capacity for rigging of up to 6 cabinets

CB-CXA12

Ceiling Bracket for CXA-12

ST-CXA

0º stack adaptor for either the CXA-12 or the CXA-18S together with CXA-12

FFC-2CXA12 & C-3CXA12

Flight case to transport 2 and 3 CXA-12

DSP configuration

DSP panel configuration

On the back pannel of the cabinet you will find the digital control area. From the compact joystick located below the screen you are able to configure the basic adjustment functions of the internal DSP.

Just move the joystick to select the icons on the left of the screen. You can enter into the following functions: Home, settings, folder, configuration and information. Please note that you must apply the desired configuration in each one cabinet and requires electrical power to work.

If changes are not made the display will automatically dim to avoid unnecessary light in situations where light is not wanted. To re-activate the light simply press the joystick.

The following screens are an example and may vary slightly for each cabinet.

HOME

On the main screen you can see the cabinet’s input and output:

• Input: You can see a vumeter with the input level and a clip signal.

• Output: You have a vumeter with the output level (0 dBu is the amp’s maximum level) You can check the compressor and control the dynamic activity.

SETTINGS

This panel allows you to change the gain, polarity, mute and the delay for the inputs.

You also have the possibility of putting a high pass, changing the type of filter, frequency and order.

FOLDER

The folder screen shows you the name of the preset and its description.

Using the joystick you can change the preset.

CONFIGURATION

This screen is to configurate Ethernet. You can choose automatic or manual.

You can also configure the screen saver.

And here you have the input selection. You can choose between analog or AES3 for channel 1 or channel 2.

INFORMATION

The last screen shows you some general information regarding the cabinet’s components.

Here you can see the cabinet model, its serial number, DSP firmware and hardware versions, amp module model with hardware version, as well as the accelerometer status.

Watch this TUTORIAL to understand how it works:

Install version

CXA-12IN

The CXA-12IN is the install version of the CXA-12 cabinet. This version is specially designed for fixed installations.

Flying frame SV-CXAIN is an unique accessory for this version, it allows you to choose between three different positions to change the array’s inclination in a more easier way.

You will find more about thisfeature in the manual.

CXA-12IN datasheet
